Cyclone dust collector
处理风量:
净化效率:
在线咨询
全国服务热线:400-118-6697

一、 Working principle of cyclone dust collector:

When the dust is drawn into the cyclone by the centrifugal fan, it will make a rotating movement from top to bottom along the wall. The dust particles are therefore separated from the airflow by centrifugal force, and then fall into the ash hopper along the wall under the action of gravity, and the gas will rotate along the discharge pipe and be discharged from the discharge pipe. The cyclone dust collector is a dry filter dust collector.

二、 the structure of the cyclone dust collector:

Cyclone dust collector is composed of intake pipe, exhaust pipe, cylinder, cone and ash hopper. The cyclone dust collector has a simple structure, is easy to manufacture, install and maintain, and the equipment investment and operation cost are low. It has been widely used to separate solid and liquid particles from the airflow.

三、The advantages of cyclone dust collector products:

⑴ The structure of the equipment is small in size, simple in structure, small in area, low in cost, low in equipment resistance, and large in handling air volume;
⑵ No rotating mechanism and moving parts, easy maintenance and management, no technical requirements;
(3) It can be used for the purification of high-temperature dust-containing gas. The cyclone dust collector made of general carbon steel can be used for 100°C flue gas purification. The cyclone dust collector of refractory material on the inner wall can be used for the treatment of 500 ℃ flue gas;
⑷Dry dust cleaning is conducive to the recovery of valuable dust;
⑸ Wide application range, wear-resistant, corrosion-resistant lining is placed in the dust collector, which can be used to purify flue gas containing high corrosion dust.
