Waste tire pyrolysis equipment

Waste tire pyrolysis equipment can make waste tyres become fuel oil, carbon black and steel wire. The manufacture of Waste tire pyrolysis equipment makes it a reality that waste tire resources renewable.

The main workflow of Waste tire pyrolysis equipment is as follows:
1. Put the waste tyres into the reactor and rotate the reactor clockwise. Seal the inlet door to ensure no gas leakage.
2. Heat the reactor slowly with heating materials. When the temperature reaches about 250 degrees, the waste tyre will be pyrolyzed and produce oil gas.
3. Oil gas from the reactor enters the condensing system, which is cooled down to liquid oil. Thencollect liquid oil by the storage tank. Gases that cannot be liquefied under normal pressure will be recovered to the combustion system through a safety device. The gas can be used as fuel to heat the reactor.
4. After the liquid oil is collected, the reactor temperature will decrease. When the temperature drops to about 40 degrees, we can expel carbon black and steel wire.
The advantages of Waste tire pyrolysis equipment:
As the professional pyrolysis equipment manufacturer in China, the waste tire pyrolysis equipmentt produced by LEFILTER company has the characteristics of safety, energy saving, environmental protection and high efficiency.
1. Safety
Waste tire pyrolysis equipment with mature safety devices, such as thermometers, pressure gauges, safety valves, electronic control systems. These safety devices can monitor the operation of waste tyre to fuel oil recycling plant at any time, and can ensure the accuracy and safety of operation.
2. Energy saving
Combustible gas that cannot be liquefied under normal pressure can be recycled and used as fuel to heat the reactor. The reuse of this gas can save fuel costs in the production process of waste tyre to fuel oil recycling plant.
3. Environmental protection
All parts of Waste tire pyrolysis equipment sealed well, will not leak. The flue gas produced in the production process is also treated by the smoke cleaning system to ensure that the exhaust smoke is pollution-free.
4. High efficiency
Waste tire pyrolysis equipment can deal with the waste tyre in batch, so that the waste tyre can be converted into fuel oil thoroughly and efficiently.
Application of final product from Waste tire pyrolysis equipmen:
The final products from Waste tire pyrolysis equipmen are pyrolysis oil, steel wire and carbon black.
1. Pyrolysis oil can be used as industrial fuel material for combustion, or further refined into diesel oil by pyrolysis oil distillation plant.
2. Carbon black can be used as clay to make bricks or as industrial additive.
3. Steel wire can be sold directly or recycled to produce new steel products.
At the moment, waste tire pyrolysis equipmen is very practical solid waste treatment method. LEFILTER's waste tire pyrolysis equipmen are exported all over the world.
