Attribute:

P/N. LES-2666
Input material Waste tyre
Output products Fuel oil carbon black steel wire flammable gas
Capacity/batch 9-10 tons/day.
 Land request 200-300 m2
Certification CE ISO SGS BV
Material of reaction kettle Q345R+Boiler plate/Stainless steel.
Cooling system BOX condenser
Emission standard 100% non-pollution

Waste Tire to Oil Pyrolysis Machinery

Waste tire to oil pyrolysis machinerymain operating process :

1. Use mechanical waste plastic to enter the reactor and close the inlet to prevent gas flow out
2. Carbon, wood or fuel heating reactor, the reactor is generally 200-300 degrees began cracking reaction, when the waste tires vaporized into oil vapor.
3. Hydrocarbons entering the condensing system are liquefied into oil and collected in the tank unit. Our system has a negative pressure device, he can greatly improve the production of pyrolysis oil.
4. At atmospheric pressure can not be liquefied petroleum gas as fuel for combustion returned to the reactor, not only energy saving and environmental protection,
5. After the oil production is completed, the reactor will be cooled. When the temperature drops to 40 degrees, the carbon black will be removed automatically or manually.

For waste tire to oil pyrolysis machinery main are as follows:

1. Reactor manufactured according to the standard, using 16mm thick boiler steel pipe and arc pressure head, can withstand high pressure and high temperature.
2 .High standard 3-step welding process, not easy to crack, long service life.
3.Pinion rotation device, small power, no direct contact with the reactor, heat transfer less easily deformed.
4. The tertiary cooling system uses a tube condenser, also known as a heat exchanger, which is currently the most commonly used and best performing condenser in the oil industry. Can ensure that the cracked oil and gas fully cooled, high oil production.
5. Safety device oil-water separator, water seal, vacuum device, to ensure the safe and efficient operation of equipment.
